At VINAYAK CONSTRUCTION EQUIPMENTS – INDIA, we offer Thermoplastic Road Marking Machine, which is named so because it employs thermoplastic paint for coating. Thermoplastic is a hot-applied road marking Machine compound for making highly reflective striping at night,day along with wet conditions. This material is based on either alkyd or hydrocarbon resins and has a considerable portion of premixed glass beads. This material is applied hot on the surface of the road and then it is left to set on. This material has excellent durability and is apt for all types of roads.This paint has incrediblelife expectancy as compared to any other types of paint used in the marking of roads.
We are one of the chief Thermoplastic Road Marking Machine Manufacturers in India. Making energy efficient, cost-effective and user-friendly road marking equipments is our chief aim. Our machine performs reliably and offers break free operation.It offers maximum performance with minimum effort. We maintain International quality standards in the designing as well as production of our machine while offering them at a very affordable price hence our road marker machines are immensely demanded in the national as well as the international Market.
The prominent characteristics :-
- Rotor Glass Bead System.
- (Air Jacked) Operator propelled 100 kg. Tank Capacity.
- Chassis built from Mild steel tubular section set with screed box made up of heat treated MS Metal.
- Positive dispensing glass bead spraying mechanism prevents waste of glass bead because it sprays glass bead only when mandatory.
- The components of this machine such as LPG burners, Torch, Valves and pipes are of highest Standard available in the heating industry; hence our machine has safe operation.
Specifications:-
- Is specifically designed for Heating the thermoplastic material & application rapidly as well as proficiently.
- Has Stainless Steel tank of 100 kg which is makes direct heating of thermoplastic material in applicator machine feasible.
- Offers trouble-free and incessant swapping out for spot application of the thermoplastics coating.
- Exceptional self-wheel lock on rear wheel to obtain a perfectly straight line.
- For heating facility, LPG is delivered to the burner for Tank, Screed Box 2 Burners and Hand Torch
- Screed Box hook mechanism offer precisely cut & sharp smooth strips,
- Screed Box hook mechanism is equipped with easy thickness modification system to alter the thickness of thermoplastic road.
- Positive dispersion of Glass Bead Spraying of Glass Bead Spraying Mechanism automatically activates with movement of the Machine with glass bead flow adjustment to let easy operation.
Thermoplastic Road Marking Machine Manufacturer
| TECHNICAL SPECIFICATION:- | |
| Thermoplastic Tank Capacity | 100 Kgs. Capacity with option to Remove/Interchange |
| Glass Bead Container | 10 Kgs. Capacity |
| Screed Box For | Marking available in 150 mm, 200 mm, 300 mm, and 500 mm (Customized Width Screed Box Available) |
| Glass Bead Spraying | Rotor Type Spraying Mechanism |
| Front Wheels | 2 * 250 mm Diameter |
| Rear Wheels | 1 * 150 mm Diameter |
| Heating System | LPG Supply to burners |
| Dimensions | 1200 L * 600 W * 900 H |
| Weight | 175 Kgs. |
Application
Although our Thermoplastic Road Marking Machine is useful in marking all types of Road to regulate traffic as well as maintain safety, they are chiefly used in highways, airports, parking plots, run ways etc.
Overall our machine is appropriate for small as well as big projects.
